High Volume

Moving an impressive 3.3lbs or 1.5kg of oxygen per horsepower hour and pumping over 900GPM or 198 m3/hour, Otterbine’s experience in wastewater treatment is obvious in the performance and results delivered by the High Volume Industrial Aerator. Constructed from stainless steel, thermoplastics and a rugged low speed motor; this system is built to withstand the demands of severe aquatic environments.

Features

Our most powerful aerator, the High Volume is chosen for its rugged design and its impressive oxygen transfer and pumping rates.

Specifications

View the product specifications.

Unit Design

Otterbine Industrial Aerators have been designed and engineered by expert craftsman to provide a high quality, ease of use product that delivers results in severe aquatic environments.

Installation

The High Volume arrives partially assembled and installation can be performed in just a few steps.

Maintenance & Winterisation

Otterbine High Volume units require minimal maintenance to ensure years of dependable service.

Features

Our most powerful aerator, the High Volume is chosen for its rugged design and its impressive oxygen transfer and pumping rates. Meeting the demands of severe aquatic environment and backed by a comprehensive 3-year warranty, check out some of the other features it offers:

Energy Efficient

Low amperage systems mean less electrical consumption and low running costs.

Complete Package

Most systems come complete with unit, power control centre, and cable with cable quick disconnect for ease of installation.

Proven Performance

Otterbine is the only manufacturer to have oxygen transfer and pumping rates independently tested and published on their aeration systems. The High Volume offers the highest oxygen transfer and pumping rates in the industry.

Shallow Operating Depth

The High Volume operates in 32in or 81cm.

Versatile

Suitable for use in a variety of applications from wastewater treatment to effluent ponds.

Safety Listed & Protected

Package electrically safety tested and listed with ETL, ETL-C. Products for European Union are also safety tested, approved and carry a 3rd party independent CE mark.

Specifications

60Hz	1HP	2HP	3HP	5HP
Spray Height (ft)	1.5	2	3	4.5
Spray Diameter (ft)	4	7	9	11
GPM	920	1525	2100	3000
Voltage/Phase/Amp 1725rpm@60Hz	115/1/13.4 230/1/6.8	230/1/11.9	230/1/13.5 230/3/8.5 460/3/4.2	230/3/14.4 460/3/7.5

50Hz	1HP	2HP	3HP	5HP
Spray Height (m)	.5	.6	.9	1.1
Spray Diameter (m)	1.2	2.3	2.6	3.5
m3/hr	198.5	329	453.1	647.2
Voltage/Phase/Amp 1425rpm@50Hz	230/1/8	230/1/12	230/1/14 400/3/4.2	400/3/7.2

Unit shipped complete with unit, cable and Power Control Center. 50Hz applications do not receive a Power Control Center. Unit average weight is 205lbs or 93kg. Minimum operating depth is 36in or 92cm. Spray performance and pumping rates are approximate

Unit Design

Otterbine Industrial Aerators have been designed and engineered by expert craftsman to provide a high quality, ease of use product that delivers results in severe aquatic environments.

Components are manufactured of 18 gauge/316 stainless steel or thermoplastics to withstand the demands of severe aquatic environments & can be used in brackish and effluent conditions.

Protective arms secure motor unit and allow for easy handling.

Protective arms secure unit, while a low-speed custom built motor with dynamically balanced rotors is designed to move high volumes of water and perform in severe aquatic environments.

Rugged closed cell foam filled low visibility polyethylene float.
Precision pitched stainless steel impeller is virtually unbreakable.
Protective arms secure motor unit and allow for easy handling.
Electrical disconnect is part of upper plate to prevent accidental damage.
Enclosed in a corrosion resistant, durable 18 gauge/316 grade stainless steel motor housing, the oil-cooled, efficient 1725/1425 RPM custom built motor has dynamically balanced rotors to move high volumes of water.
